CPM Products
CPM Pellet Mill
CPM’s model 1100 Pellet Mill is our smallest production-scale pellet mill. Utilizing the same design concepts we apply to our larger pellet mills, it is built to provide years of reliable, economical service.
Features
- Single-reduction gear drive
- Small enough for pilot plants
- Ideal for small batches and short production runs
- Durable enough for 24-hour operation
The 3000 Series Pellet Mills are popular for general-line feed mills, plastics, industrial products and shrimp feeds. They have replaced the popular CPM Century line of pellet mills.
Features
- Splash lubrication
- Remote roll adjusting (lineator)
- Roll speed measurement (RSM) on select models
The 7700 Series Pellet Mill is part of our intermediate pellet mill line with the same features as our higher-capacity and larger-horsepower pellet mills.
Features
- Forced oil lubricated gearbox
- Range of die sizes
- Gear train that handles 200-300 horsepower
- Splash lubrication
- Remote roll adjusting (lineator)
The 7900 Pellet Mill is the workhorse and go-to pellet mill for many applications. Whether it is hard-running biomass, high-capacity animal feeds or anything in between, the 7900 is known for its dependability and versatility.
Features
- 7900 industry-standard gear box
- Largest range of die sizes of all CPM pellet mills
- Largest range of gear sets of all CPM pellet mills
- Largest range of horsepower for all CPM pellet mills
- Splash lubrication
- Remote roll adjusting (lineator)
- Roll speed measurement (RSM) on select models
Our 9036 and 9042 Series Pellet Mills are built for rugged work and high capacity. For applications that require high horsepower-to-working-die surface area, the 9036 is the answer. For high-capacity applications such as oilseed meal or broiler feeds, which need increased die area, the 9042 is designed to run day-in and day-out with high output per hour.
Features
- Splash lubrication
- Remote roll adjusting (lineator)
- Roll speed measurement (RSM) on select models
California Pellet Mill’s model 9950-14 is the culmination of more than 80 years of pellet mill engineering and applications expertise. At almost 2,200 square inches (14,190 cm²) of die area, it is the largest ring-die pellet mill in the world. It is designed for high-capacity applications such as integrated swine, turkey and broiler feeds.
Features
- Single-reduction gearbox
- Two-roll main shaft for maximum energy efficiency
- Splash lubrication
- Remote roll adjusting (lineator)
- Roll speed measurement (RSM) on select models
Coolers
A good pelleting system is never complete without a good cooler. That’s why CPM provides coolers that give you optimum cooling and drying to cater to your needs. Designed with minimal floor space in consideration, CPM offers cooler in a variety of width and length with options to match their specific cooling needs. High efficiency and ease of operation. Get yours from CPM now!
The Heavy-Duty Horizontal Dryer/Cooler by CPM Roskamp is designed for the most demanding cooling and drying applications. Perfect for popular applications including pellets, meal, expanded collets and cake and more, the HDHC Horizontal Dryer/Cooler offers multiple feeder, plenum and steam coil options. Along with CPM’s expert knowledge and support, this machine is ready for anything.
Features
- 3-foot to 8-foot widths
- 9-foot to 63-foot lengths
CPM Counterflow Cooler is one of the most advanced cooler available in the market. Its simple design, mechanically trouble-free and minimal space required, makes it the preferred choice and highly sought after cooler. CPM Counterflow coolers provides efficient moisture control and low-shock tempered cooling.
Features
- Provides moisture control
- Ensures pellet durability
- Efficient
- Trouble-free
Choice of Discharge System
- Sliding Grid
- Rotary Grid
Crumbler
CPM Crumblers are well known for being high capacity and high efficiency in the market. Its compact installation and high quality construction make these machines one of the best available. Keeping its design simple throughout these years, you can rely on CPM for high efficiency and ease of operation always.
Key Advantages
- Robust construction ensures maximum performance, 24*7.
- Load-centering bearing supports & unique bearing slides assure accurate, consistent production.
- Roll corrugation and speed differential ratios
- Roll corrugations last 90-100 days at full capacity
- Easy access doors for roll change with minimal disassembly required
- Improved IRD belt wrap minimizes slip, Fans behind roll sheave circulate air, Reduce belt temperature and increase belt life, Guard design allows easy access for MD & IRD, IRD belt wrap & idler simplify belt change, Roll parallel adjustment is quick and easy.
Conditioners
CPM Conditioners provide the optimum preparation of mash prior to pelleting. The optimum conditioning of feed allows you to get the best performance out of a CPM pellet mill. It also gives a higher production throughput, better pellet durability and improved digestibility at a reduced pellet mill power consumption. Made from stainless steel and comes with a feeder magnet and optional features, our conditioners are definitely cost effective. Complete your CPM pellet mill with a CPM Conditioner to ensure that you get the best pellets.
The Feeder comes in 2 sizes ; 9.5″ and 12″ catering to customer’s requirement. The feeder, made of heavy duty shell, also comes with the options to include a magnet (to remove metal objects) and a variable frequency drive to control the speed of the feeder to allow constant flow of mash.
Features
- Heavy duty, stainless steel construction
- Adjustable picks
- Single or stacked configurations
- shaft-mounted gear-reducer drives
- 80 to 300RPM shaft speeds
- Single or stacked configurations
The Feeder comes in 2 sizes ; 9.5″ and 12″ catering to customer’s requirement. The feeder, made of heavy duty shell, also comes with the options to include a magnet (to remove metal objects) and a variable frequency drive to control the speed of the feeder to allow constant flow of mash.
Features
- Heavy duty, stainless steel construction
- Wide and fully adjustable picks
- Single or stacked configurations
- Wide range of diameter and length
Benefits
- Excellent moisture absorption and temperature increase
- Flexibility for plant layout and desired retention time
- Easy access for pick setting
- Maximum conditioning by incorporating steam and other liquids
The Hotstart (HS) conditioner is one innovative way to ensure that meals receive the optimum conditioning required before being pelleted. The advantage of HS conditioner is that the meal temperature preset by the customer is reached before being discharged. This in return helps to produce cost efficient, high quality pellets.
Features
- Heavy duty, stainless steel construction
- Steam or heat traced jacket to prevent escape of steam
- Variable frequency drive to reverse shaft speed and direction
- Program controlled shaft speed and direction
- Temperature monitoring
Benefits
- Excellent moisture absorption and gelatinization
- Desired temperature control
- High quality output and cost effective operation
- Maximum conditioning by incorporating steam and other liquids
Hammer Mill
Champion hammermills are designed to meet almost any particle size reduction need and are capable of fine-grinding either friable or fibrous materials. These rugged, highly efficient hammermills offer standard and optional features for custom grinding and size reduction solutions and total dependability. On top of offering outstanding ease-of-operation, Champion hammermills are backed by the best support in the industry.
The HM Series 38″ Hammermill features a screen area of 1,728 by 5,184 square inches and an HP range of 75-450.
Features
- Double-wall box construction filled with vibration-dampening material
- Mechanical steel tube base
- Double-pivot full-access doors
- Inboard and outboard double-row spherical roller bearings
- Dual hammer position
- Patented regrind chamber
- Premium Diamond hammers
- Bearing temperature monitor probes
- Vibration switches
- Trap key interlock
- Replaceable AR235 abrasion-resistant wear liners
The HM Series 44″ Hammermill features a screen area of 1,920 by 5,760 square inches and an HP range of 100-500.
Features
- Double-wall box construction filled with vibration-dampening material
- Mechanical steel tube base
- Double-pivot full-access doors
- Inboard and outboard double-row spherical roller bearings
- Dual hammer position
- Patented regrind chamber
- Premium Diamond hammers
- Bearing temperature monitor probes
- Vibration switches
- Trap key interlock
- Replaceable AR235 abrasion-resistant wear liners
The HM Series 54″ Hammermill features a screen area of 2,368 by 7,104 square inches and an HP range of 125-500. The high tip speed and fine grind options on our HM Series 54″ Hammermill makes it the industry standard for ultrafine grinding.
Features
- Double-wall box construction filled with vibration-dampening material
- Mechanical steel tube base
- Double-pivot full-access doors
- Inboard and outboard double-row spherical roller bearings
- Dual hammer position
- Patented regrind chamber
- Premium Diamond hammers
- Bearing temperature monitor probes
- Vibration switches
- Trap key interlock
- Replaceable AR235 abrasion-resistant wear liners
